EMS Facility

⦿ High-end SMT System Complete with pick & place, printer, reflow oven, AOI and BGA work station.
⦿ Hi-Rel Facility With professional class Weller soldering & rework station, Leica microscope up to 50x zoom.
⦿ Cleanroom Environment Facility for class 1,00,000 standard.
⦿ Laminar Airflow System Class 100 for Hi-Rel work.
⦿ ESD Safe Floor, work area & tools.
⦿ High and standards compliance Of Hi-rel standards for day-to-day work.
⦿ Trained & Qualified Manpower For complex Hi-Rel work.
⦿ ISO Registered and BIS Certified Products

Infrastructure of MCBS-EMS

MCBS-EMS is located in a pollution-free electronics area of 10,000 square meters (100,000 square feet) with a built-up area of 60,000 square feet, which houses manufacturing, assembly and integration, R&D facilities, marketing, warehouses, and other departments.

Clean room environment with 1,00,000 standard

High end & High speed SMT line for RoHS & Non-RoHS capability

Dedicated PTH assembly with wave soldering for RoHS & Non-RoHS

Hi-Rel facility with necessary tools for space, Defence work

In-Line AOI Leica Microscope 50X zoom, BGA rework station

End-to-End solutions for Hardware & software applications

Manufactured & supplied more than 200 projects of all types for professional industry organizations

Qualified and trained manpower to plan and execute projects

Development Services

STENCIL PRINTER | XPERT 3 | EKRA, GERMANY

* PCB Size 508x508mm.
* Fully Automatic Printer.
* Process alignment capability 2 Cpk @ ± 15μm.
* Automatic Cleaning.
* Paste Coverage inspection.

PICK & PLACE | NPM–W2 | PANASONIC, JAPAN

* 220 Feeders, Automatic 20 Tray
* Part Handling: 0.6x0.3mm (0201) to 35x35mm
* Board Size: 750mm to 460mm
* Rated Speed:125000cph
* Placement Accuracy: ±30 micron Cpk ≥1.0
* Intelligent Tape feeders & Stick Feeders

REFLOW OVEN | MR933+ | VITRONICS, USA

* 9 TOP+BOT Heating Zones.
* 3 TOP+BOT Cooling Zones.
* Smart Board Tracking.
* Width Adjustable Chain Conveyer.
* Auto Lubricant System.

AUTOMATIC OPTICAL INSPECTION | S3088 | VISCOM, GERMANY

* Large FOV 57.6 x 43.5 mm, Scanning speed of 1200 fps [frames per Linear Motors on X & Y Axis
* 4 Top and 4 Angular cameras.
* Each Camera is 5 Mega Pixel and module cumulates to 20-60 Mega Pixel size

WAVE SOLDER MACHINE| EMS TECHNOLOGY| INDIA

* This Unit Contain Spray Fluxer (5Ltr.+1Ltr. Solvent)tank.
* It has 150Kg Of Solder Bath Pot
* Conveyor Speed 0 to 2 Min
* Conveyer Angle 4 & 5 Degree
* Max. Width Up to 300mm

BGA REWORK STATION

* Heating Method: Infrared (IR) and hot air
* Maximum PCB Size: 400mm x 400mm
* Placement Accuracy: ±0.01mm
* Component Types: BGA, QFN, CSP, μBGA
* Temperature Control: PID with real-time monitoring
* Features: Bottom heater for preheating, vision system for alignment, reflow profile customization

AUTOMATIC FLASH PROGRAMMER

* Supported Devices: EEPROM, Flash memory, Microcontrollers
* Programming Speed: Up to 1000 devices per hour
* Interface: USB, Ethernet
* Programming Algorithms: Universal and device-specific algorithms
* Features: Automated socket handling, barcode scanner support, self-calibration

TINNING & DE-GOLDING POT

* Pot Capacity: 10kg
* Heating Method: Induction heating
* Temperature Control: Digital, adjustable up to 450°C
* Flux Type: Water-soluble flux
* Flux Capacity: 2 liters
* Features: Automatic flux replenishment system, fume extraction

SOLDER PASTE MIXER

* Capacity: 500g to 20kg batches
* Mixing Time: Adjustable from 1 to 10 minutes
* Rotational Speed: 500 to 2000 RPM
* Vacuum Mode: Yes, for air bubble removal
* Programmable Settings: Temperature, mixing duration, rotation speed
